FPGA LCMXO3LF 6900C EVN

FPGA LCMXO3LF 6900C EVN

Features FPGA LCMXO3LF 6900C EVN
The MachXO3 Starter Kit includes:
• MachXO3L/LF Board – The board is a 3” x 3” form factor that features the following on-board components and.
circuits:
— MachXO3 FPGA – LCMXO3L-6900C-5BG256C (NVCM Based) or LCMXO3LF-6900C-5BG256C (Flash.
Based)
— USB mini-B connector for power and programming.
— 4-Mb Serial Flash Memory for boot image and dual-boot support.
— Eight LEDs.
— 4-position DIP switch.
— Momentary push button switch.
— 40-hole prototype area.
— Four 2 x 20 expansion header landings for general I/O, JTAG, and external power.
— 1 x 8 expansion header landing for JTAG.
— 1 x 6 expansion header landing for SPI/I2.
C
— 3.3 V and 1.2 V supply rails.

Features

The MachXO3 Starter Kit includes: MachXO3L/LF Board ­ The board x 3″ form. factor that features the following on board components and circuits. MachXO3 FPGA ­ LCMXO3L-6900C-5BG256C (NVCM Based). or LCMXO3LF 6900C 5BG256C (Flash Based). USB mini-B connector for power and programming. 4Mb Serial Flash Memory. for boot image and dual boot support. Eight LEDs 4 position DIP switch. Momentary push button switch 40 hole prototype area Four x 20 expansion. header landings for general I/O, JTAG. and external power x 8 expansion. header landing for JTAG x 6 expansion header landing. for 3.3 V and 1.2 V supply. rails Pre-loaded Demo.­ The kit includes a pre-loaded counter design that highlights use.

of the embedded MachXO3 oscillator. and programmable I/Os configured for LED drive. USB Connector Cable ­ The board is powered. from the USB mini-B socket when connected to a host PC. The USB channel also provides a programming. interface to the MachXO3 JTAG port. Lattice Development Kits and Boards Web Page ­ Visit www.latticesemi.com/breakoutboards for the latest. documentation (including this guide) and drivers for the kit. The content of this user’s guide includes
